EMT TSD SPH Phono Cartridge
EMT TSD SPH Phono Cartridge
The TSD SPH fits the Tondose with a spherical stylus of the kind in general use before 1980 — a design that can produce excellent results on early stereo LPs. The traditional EMT stereo generator in the magnesium monobloc housing, for records that were cut when this was the reference geometry. Mount is specified at order — X (SME style), EMT, or INT (Ortofon A). The TSD SFL is pictured; all Tondose models share the same housing.
Specifications
| Format | Tondose — integrated-headshell cartridge, magnesium monobloc |
|---|---|
| Diamond | SPH 15 µm spherical |
| Cantilever | Aluminium |
| Transducer | MC Stereo |
| Mount | X (SME style), EMT, or INT (Ortofon A) — specified at order |
| Tracking force | 2.5 g |
| Output voltage | 1.00 mV @ 5 cm/s |
| Compliance | 12 µm/mN |
| Impedance | 24 Ω standard; 12 Ω and 6 Ω coils to order |
| Recommended load | 200–300 Ω |
| Coil | Copper standard; silver or gold coil to order |
Call or visit the showroom about availability. Contact our team for pricing, a demonstration, or system design — get in touch.
Or call (512) 883-0844
Pricing on request. Call or visit the showroom about availability.
