EMT TSD MRB Phono Cartridge
EMT TSD MRB Phono Cartridge
The TSD MRB puts a highly polished multi-radius diamond on a boron cantilever inside the legendary Tondose — the integrated-headshell EMT cartridge, milled from a solid block of magnesium since the line's 80th-anniversary revision. Highest-resolution tracking in the classic broadcast format, for EMT tonearms and their kin. Mount is specified at order — X (SME style), EMT, or INT (Ortofon A). The TSD SFL is pictured; all Tondose models share the same housing.
Specifications
| Format | Tondose — integrated-headshell cartridge, magnesium monobloc |
|---|---|
| Diamond | MR HP |
| Cantilever | Boron |
| Transducer | MC Stereo |
| Mount | X (SME style), EMT, or INT (Ortofon A) — specified at order |
| Tracking force | 2.5 g |
| Output voltage | 1.00 mV @ 5 cm/s |
| Compliance | 12 µm/mN |
| Impedance | 24 Ω standard; 12 Ω and 6 Ω coils to order |
| Recommended load | 200–300 Ω |
| Coil | Copper standard; silver or gold coil to order |
Call or visit the showroom about availability. Contact our team for pricing, a demonstration, or system design — get in touch.
Or call (512) 883-0844
Pricing on request. Call or visit the showroom about availability.
