The DAC9 combines a vacuum-tube analog section with the latest digital design, decoding DSD music files and PCM files up to 384kHz through two separate data paths that ensure proper integer decoding. Quad D-A converters run dual stereo DACs in mono per channel to increase dynamic range and lower the noise floor, with selectable digital filters and native-rate upsampling on all inputs. The balanced, Class-A, zero-feedback analog section uses a pair of 6H30 dual-triode tubes with no capacitive coupling, fed by an asynchronous USB input and four galvanically isolated SPDIF inputs.
Specifications
Analog stage
Balanced, Class A, zero feedback, no capacitive coupling
DAC architecture
Quad D-A converters, dual stereo DACs per channel in mono
Dimensions
19 in W x 7 in H x 15.5 in D, 32 lbs net
Inputs
Asynchronous USB 2.0HS (44.1kHz to 384kHz PCM, DSD, 2xDSD); RCA, BNC, XLR to 192kHz; Toslink to 96kHz
Signal-to-noise ratio
Greater than 114dB
Tube complement
Two 6H30 dual triodes
Upsampling
All inputs upsample to 384kHz
