Typhon T30 is the 30 A version of the Typhon: a 6 gauge ArNi VTX-Ag buss fed through a proprietary 30 A Amphenol twist-lock inlet, with two 20 A NEMA 5-20R outlets and a 30 A Amphenol output that can feed a second distributor or an amplifier through a T30 umbilical. Three isolation zones, a hydraulic electromagnetic breaker and more than 50 dB input to output noise reduction. It needs the T30 power cable, listed separately, and is built for a 120 V or 240 V 30 A circuit, in silver or black.
Specifications
Construction
All-aluminum chassis, brushed anodized faceplate
Dimensions
17 in W x 10 in D x 4.4 in H
Feet
SSF-38 stainless steel
Finish
Silver or black
Inlet
Proprietary 30 A Amphenol twist-lock (T30 cable required)
Input current
30 A
KPIP v2 processing
4 days
Made in
Poulsbo, Washington, USA
Mains
120 V or 240 V versions
Noise suppression
More than 50 dB input to output, more than 40 dB zone to zone
Outlets
2 US NEMA 5-20R at 20 A, one 30 A Amphenol output, three isolation zones
Protection
Hydraulic electromagnetic breaker, 40,000 A transient
Series
Reference
Weight
17.5 lb
Wiring
6 gauge ArNi VTX-Ag buss
Call or visit the showroom about availability. Contact our team for pricing, a demonstration, or system design — get in touch.
