The DA-07X is a standalone USB D/A converter derived from the D-07X player, with the disc mechanism removed and functionality, connectivity and sound quality refined for the streaming era. Dual ROHM BD34301EKV chips operate in monaural mode, accepting PCM up to 768kHz/32-bit and DSD up to 22.5MHz over USB, with coaxial, optical and AES/EBU inputs for legacy sources.
Specifications
D/A converter
ROHM BD34301EKV (monaural mode) x 2
USB input
PCM up to 768kHz/32-bit, DSD up to 22.5MHz
Digital inputs
USB, coaxial, optical, AES/EBU
Analog output
2.4V unbalanced / balanced
S/N ratio (IHF-A)
124dB
Dimensions
440 x 92 x 402 mm (W x H x D)
Weight
12.8 kg
